BC 54

As a first step, check if your blood pressure monitor has the Bluetooth^® connection enabled. You will find the instructions to activate the Bluetooth^® connection in the user manual of the blood pressure monitor. You can also find it at the following link: Manuals

Turn on the Bluetooth^® on your smartphone and then open the app "beurer HealthManager".

Pair your Beurer device exclusively through our app and not through the direct Bluetooth^® settings of your smartphone.

Restart your smartphone.

Open the app "beurer HealthManager" and go to Settings / Devices / Add device and select your device that you want to pair with the smartphone. Follow the instructions of the app so that the pairing can be completed.

The data will then be automatically transferred to the smartphone after the measurement.

If the connection is still not possible, you should check the compatibility of your smartphone with the device and the app.

If your smartphone is not compatible, no pairing is possible. You can find the list of supported smartphones here: System requirements

When setting up the blood pressure monitor, if the current date is not set, the measurement data will not be displayed in the HealthManager Software. The HealthManager is configured so that only measurement data of the current date are visible. Consequently, measurement data from the distant past or future are not visible.

Please therefore check with the help of your device's user manual whether the correct year has been set. The setting of the year takes place during the initial setup directly on the display of the blood pressure monitor. While measuring, you cannot see the year in the overview.

In the user manual, you will find the instructions for the initial setup of your device. The appropriate user manual for your device can be found here: User Manuals

Please note that only newly recorded measurements are displayed in the app or software.

As a first step, check if your blood pressure monitor's Bluetooth® connection is enabled. After that, you can start the pairing process.

The instructions for activating the Bluetooth® connection can be found in the user manual of the blood pressure monitor.

Open the app "beurer HealthManager" and go to Settings / Devices / Add device / Blood pressure and select your blood pressure monitor. Then follow the instructions in the app.

Should a PIN be required, the 6-digit PIN appears on the display of the blood pressure monitor. Please enter 0000 or 1234 as the PIN in the app.

The PIN code is entered from "left to right" and "top to bottom".

After entering, the data transfer from the app "beurer HealthManager" is automatically started.

The usual values for normal blood pressure are:

• Upper limit values: Systole 140 mmHg / Diastole 90 mmHg
• Ideal values: Systole 120 mmHg / Diastole 80 mmHg

The measurement on the wrist joint must be done so that the wrist is at the level of the heart. If the arm is laid flat on the table in a sitting position, for example, the blood pressure is overestimated by about 7-8 mmHg because there is a difference to the height of the heart (1.5 cm corresponds to 1 mmHg).

Faulty measurement results can also arise during wrist joint measurement in cases of heart rhythm disturbances and changes in the arteries at the wrist joint (e.g., age-related). In particular, in older people, wrist joint measurements can therefore sometimes provide inaccurate results. The arteries at the upper arm are not as sensitive to such influences. Therefore, comparative measurements at the upper arm are recommended.

At the start of many of our blood pressure monitors, the device automatically performs a brief self-test and displays the full display during this phase. However, this display does not indicate the charging status of the battery. Only when the corresponding error message described in the operating instructions is shown on the display, is a battery replacement necessary.

Please note that for most devices, the date and time can only be set when they are switched off. Therefore, leave the device in the switched-off state and proceed as described in the usage instructions. Typically, there are two different ways to access the menu for setting adjustments:

1. When using the device for the first time or whenever batteries are newly inserted, most devices automatically enter the corresponding menu.
2. With already inserted batteries, one of the function keys must be held down for a certain time while the device is off. Details on the procedure can be found in the operating instructions.

Please ensure that the tab on the left side is inserted correctly.
Also check whether the batteries are correctly inserted and also fully charged. Depending on storage duration, the batteries might discharge.
Do not turn on the blood pressure monitor, please contact our customer service.

Before each measurement and between successive measurements, a pause of at least one minute should be taken.

The Beurer blood pressure monitors are already calibrated in software. During production, they are tested for accuracy at 100%. Recalibration is not necessary.

The blood pressure monitor can differentiate the readings of individual users. Please note that the app "beurer HealthManager" can only manage one user at a time. To separate the readings of individual users in the app, each user should register with their own email address in the app and select the correct device specification in the app, so that these are correctly separated.

Blood pressure and pulse are dependent on many factors that can also have a short-term influence:

• Short-term influences
• Mental influences
• Physical movement
• Muscle tension
• Speech
• Excitement
• Noise etc.

Furthermore, the correct application of the blood pressure monitor is of high importance for reliable and accurate measurement results. Application errors during measurement can have a significant influence on the accuracy of the measurement:

• The cuff was too tight / too loose
• The cuff is not at heart level
• Too short a pause between measurements
• No optical or acoustic isolation of the specimen

For this reason, certain rules should be observed during blood pressure measurement. We also show you how to measure your blood pressure correctly in our video tutorials.

Naturally, device tolerances also come into play. With devices with a manometer (pressure gauge), the parallax error (reading error) additionally occurs. Please ensure that at least a 1-minute pause is taken between consecutive measurements.

Blood pressure values, which are measured in the medical practice by the doctor themselves or by the practice staff using the standardised Riva-Rocci method through listening to the so-called Korotkoff sounds, are usually somewhat higher than those obtained through self-measurement in a relaxed domestic atmosphere. One speaks of a "practice" or "white coat hypertension". People who have elevated blood pressure under the stress of everyday conditions can show normal values under the calm conditions at the doctor's. Here one speaks of "practice-normotension".
